角型電感式接近開關PL-08D1產品介紹

【中文版】
PL-08D1是一款專為工業自動化場景設計的角型電感式接近開關，適用于金屬物體的非接觸式檢測需求。產品采用緊湊的矩形結構設計，結合優化的電磁感應技術，能夠在復雜工況中實現穩定可靠的檢測功能。

產品優勢：

1. 結構設計合理，緊湊的外形便于在有限空間內安裝，同時棱角分明的外殼設計增強了對機械應力的耐受性。主體材質選用工程級塑料與金屬防護層復合工藝，兼顧輕量化與抗沖擊性能。
2. 檢測性能經過特殊調校，對鐵磁性金屬具備良好的檢測靈敏度，檢測距離經過精密計算，確保在設定范圍內保持穩定的檢測精度。內置溫度補償電路，可在-25℃至+70℃環境溫度范圍內維持工作參數穩定。
3. 防護性能優化，對粉塵、油霧及濕度變化具有適應性，特殊密封處理使產品能夠應對輕度腐蝕性環境。采用全封閉式結構設計，有效防止外部顆粒物侵入內部電路。
4. 支持多種安裝方式，提供側面或端面固定選擇，配備標準尺寸安裝孔位，便于集成到各類自動化設備中。輸出接線采用耐彎折線纜，端子連接方式簡化現場布線流程。

技術參數：
檢測物體：鐵系金屬（建議檢測物尺寸≥8mm）
檢測距離：最大4mm（視材質而定）
電源電壓：DC 10-30V
輸出類型：NPN/PNP可選
響應頻率：200Hz
殼體材質：增強型PBT+不銹鋼部件
防護等級：IP67
工作溫度：-25℃～+70℃

應用場景廣泛應用于自動化生產線定位檢測、機床刀具到位確認、輸送帶金屬部件計數、包裝機械位置控制等場景。典型應用包括注塑機模組定位、機械臂末端工具識別、立體倉庫貨物感應等需要精準檢測金屬物體位置的工業環境。

該產品經過嚴格的生產工藝控制與多重質量檢測程序，致力于為工業自動化系統提供可靠的檢測解決方案。我們持續關注產品在實際應用中的表現，通過不斷優化內部電路設計與機械結構，提升產品在復雜工況下的適應能力。

【English Version】
The PL-08D1 rectangular inductive proximity switch is engineered for non-contact detection of metallic objects in industrial automation systems. Featuring a compact angular housing design, this device integrates enhanced electromagnetic sensing technology to deliver consistent performance in demanding operational environments.

Product Highlights:

1. The space-saving rectangular configuration allows flexible installation in constrained spaces. The reinforced housing combines engineering-grade polymers with metal shielding, achieving an optimal balance between impact resistance and lightweight construction.
2. Precision-tuned detection characteristics ensure reliable sensing of ferrous metals within specified ranges. Integrated temperature compensation circuitry maintains operational stability across a broad temperature spectrum from -25℃ to +70℃.
3. Enhanced environmental protection design features multi-layer sealing technology, providing effective resistance against dust ingress, oil mist exposure, and humidity variations. The fully enclosed structure safeguards internal components from particulate contamination.
4. Versatile mounting options include side or end fixation configurations, with standardized mounting holes for seamless integration into automation equipment. Durable flexible cabling with reinforced strain relief ensures long-term wiring reliability.

Technical Specifications:
Target Material: Ferrous metals (recommended target size ≥8mm)
Sensing Distance: Max.4mm (material dependent)
Supply Voltage: DC 10-30V
Output Configuration: Selectable NPN/PNP
Switching Frequency: 200Hz
Housing Material: Reinforced PBT with stainless steel components
Ingress Protection: IP67
Operating Temperature: -25℃～+70℃

Typical applications encompass position verification in CNC machining centers, metal part counting on conveyor systems, tool presence detection in robotic assemblies, and material handling equipment positioning. Common implementations include injection molding machine component tracking, automated warehouse pallet detection, and production line fixture alignment monitoring.

Manufactured with stringent process controls and multi-stage quality verification, this proximity switch demonstrates consistent performance in diverse industrial settings. Continuous product optimization focuses on improving circuit reliability and mechanical durability to meet evolving automation requirements.
