【YLXA-10A拉繩開關產品簡介】
YLXA-10A型拉繩開關是一款專為工業設備安全防護設計的高效觸發裝置，適用于皮帶輸送機、物料傳輸線、礦山機械等場景的緊急停機控制。產品采用模塊化結構設計，通過機械式觸發機制實現快速斷電響應，有效提升設備運行安全系數。
外殼選用高強度鋁合金壓鑄成型，表面經多層防氧化工藝處理，可在-25℃至+75℃環境溫度下穩定運行。內部核心組件配置精密彈簧復位系統，確保觸發后自動恢復待機狀態。拉繩接口采用雙向360°可旋轉結構設計，支持多角度安裝需求且有效避免線纜纏繞。產品防護等級達到IP67標準，具備良好防塵防水性能，適應礦山、港口等復雜工況環境。
本裝置支持雙側拉繩接入模式，最大布線距離可達100米，滿足長距離設備的安全覆蓋需求。觸發機構采用低阻力滑輪組設計，操作拉力不超過20N，有效降低人員操作強度。觸點組件采用銀合金材質，接觸電阻低于50mΩ，確保信號傳輸穩定可靠。安裝支架提供壁掛式與嵌入式兩種選擇，適配不同設備的結構特征。
在維護保養方面，產品設計有可視化工作狀態指示窗，可通過外部觀察孔快速判斷裝置運行狀態。所有活動部件均預留標準化注油孔位，方便定期潤滑保養。建議每季度進行常規功能檢測，清除傳動部件積塵，及時更換磨損繩體即可保持長效穩定運行。
【YLXA-10A Emergency Pull Cord Switch Product Introduction】
The YLXA-10A emergency pull cord switch is a safety protection device specifically designed for industrial equipment, providing reliable emergency stop control for belt conveyors, material handling systems, mining machinery and other applications. Featuring a modular mechanical triggering mechanism, it ensures rapid power cutoff response to enhance operational safety.
Constructed with die-cast aluminum alloy housing treated with multi-layer anti-corrosion coating, the device maintains stable performance within -25℃ to +75℃ temperature range. The integrated spring reset system guarantees automatic return to standby mode after activation. The 360° rotatable cable gland allows flexible installation angles while preventing wire entanglement. With IP67 protection rating, it demonstrates excellent resistance to dust and water ingress, suitable for harsh environments like mining sites and port facilities.
This dual-channel device supports bidirectional cable connection with maximum wiring distance of 100 meters, enabling comprehensive safety coverage for extended equipment. The low-friction pulley mechanism requires operational force below 20N, reducing manual effort. Silver-alloy contacts ensure reliable signal transmission with contact resistance under 50mΩ. Two mounting options (surface-mounted and flush-mounted) are available to accommodate various equipment configurations.
Maintenance-friendly design includes a transparent inspection window for visual status monitoring. Standard lubrication ports are provided for periodic servicing of moving parts. Routine functional checks every quarter, combined with dust removal and timely rope replacement, will ensure long-term operational reliability. The product s streamlined structure minimizes maintenance requirements while delivering consistent emergency response capabilities.
