鎧裝鉑電阻WZPK2-325SA 廠家
產品概述（中英文）
鎧裝鉑電阻WZPK2-325SA是一種高性能溫度傳感器，采用不銹鋼保護套管和高密度氧化鎂絕緣材料制成，具有直徑小、彎曲靈活、抗震性強等特點，特別適合安裝在空間受限或需要快速響應的場合。該產品能夠精確測量-200℃至600℃范圍內的氣體、液體及固體表面溫度，并通過銅導線直接連接二次儀表，為顯示儀、記錄儀、調節器等設備提供穩定的溫度信號。其結構設計兼顧抗污染性和機械強度，適用于環境復雜的工業場景。
The WZPK2-325SA armored platinum resistance thermometer is a high-performance temperature sensor featuring stainless steel protective casing and magnesium oxide insulation. With compact diameter, excellent flexibility and vibration resistance, it is particularly suitable for installation in confined spaces or applications requiring rapid response. Capable of accurately measuring temperatures from -200°C to 600°C in gases, liquids and solid surfaces, it transmits stable signals to display instruments, recorders and controllers via direct copper wire connections. Its robust design combines contamination resistance with mechanical durability for demanding industrial environments.1519
核心技術特點（中英文）
產品采用進口薄膜電阻元件，具有熱響應時間短（直徑3mm≤3秒）、測量精度高、性能穩定可靠等優勢。鎧裝結構允許長度自由定制，且不受安裝方向限制，能夠適應管道狹窄或微型化設備的需求。內部氧化鎂絕緣層有效減少動態誤差，外管1Cr18Ni9Ti不銹鋼材質提供優異的抗腐蝕能力。獨特的可彎曲特性使其在裝配式鉑電阻無法安裝的復雜結構中展現突出優勢。
The product utilizes imported thin-film resistance elements, delivering short thermal response time (≤3s for 3mm diameter), high measurement accuracy and reliable performance. The armored structure supports customized lengths and omnidirectional installation, meeting requirements of narrow pipelines or miniaturized equipment. Internal magnesium oxide insulation minimizes dynamic errors while 1Cr18Ni9Ti stainless steel outer tube offers superior corrosion resistance. Its unique bendable characteristic provides distinctive advantages in complex installations where traditional assembled resistors are infeasible.3615
應用領域（中英文）
該產品廣泛應用于石油化工、電力能源、制藥等行業的溫度監測系統，特別適用于需要快速溫度反饋的自動化控制場景。在各類反應釜、輸送管道、熱力設備中表現優異，能夠長期穩定工作在振動、沖擊或腐蝕性介質等惡劣工況下。其標準化輸出信號可兼容絕大多數顯示儀表和控制系統，實現工業現場的精準溫度管理。
Widely used in temperature monitoring systems for petroleum, chemical, power generation and pharmaceutical industries, it excels in automation control scenarios requiring fast thermal feedback. The sensor demonstrates outstanding performance in reactors, pipelines and thermal equipment, maintaining long-term stability under harsh conditions including vibration, shock or corrosive media. Its standardized output signals are compatible with most display instruments and control systems, enabling precise temperature management in industrial settings.91322
鎧裝鉑電阻
WZPK-563U，WZPK-564U，WZPK-565U，WZPK-566U，WZPK-173U，WZPK-174U，WZPK-175U，WZPK-176U，WZPK-273U，WZPK-274U，WZPK-275U，WZPK-276U，WZPK-373U，WZPK-374U，WZPK-375U，WZPK-376U，WZPK-473U，WZPK-474U，WZPK-475U，WZPK-476U，WZPK-573U，WZPK-574U，WZPK-575U，WZPK-576U，WZPK-103S，WZPK-104S，WZPK-105S，WZPK-106S，WZPK2-105SA，WZPK2-106SA，WZPK-203S，WZPK-204S，WZPK-205S，WZPK-206S，WZPK2-205SA，WZPK2-206SA，WZPK-303S，鎧裝鉑電阻，WZPK-535S，WZPK-533S，WZPK-534S，WZPK2-436SA，WZPK2-435SA，WZPK-435S，WZPK-434S，WZPK-433S，WZPK2-336SA，WZPK-235U，WZPK-134U，WZPK-236S，WZPK2-335SA，WZPK-336S，WZPK-235S，WZPK-325U，WZPK-234S，WZPK-335S，WZPK-404U，WZPK-126U，WZPK-334S，WZPK-233S，WZPK-365U，WZPK2-136SA，WZPK-333S，WZPK2-236SA，WZPK2-135SA，WZPK-136S，WZPK2-235SA，WZPK-135S，WZPK-134S，WZPK-524U，WZPK-123U，WZPK2-525SA，WZPK-525S，WZPK-524S，WZPK-523S，WZPK2-425SA，WZPK-425S，WZPK-424S，WZP2-44SAB，WZPK-423S，WZPK-326S，WZPK2-325SA，WZPK-325S，WZPK-323S，WZPK-324S，WZPK2-226SA，WZPK2-225SA，WZPK-226S，WZPK-225S，WZPK-223S，WZPK2-126SA，WZPK2-125SA，WZPK-125S，WZPK-126S，WZPK-124S，WZPK-123S，WZPK2-506SA，WZPK2-505SA，WZP2-420D，
概述
鎧裝鉑電阻是一種溫度傳感器，它比裝配式鉑電阻直徑小，易彎曲，抗震性好，適宜安裝在裝配式鉑電阻無法安裝的場合。本公司生產的WZPK系列鎧裝鉑電阻采用引進鉑電阻測溫元件，因此，具有精確、靈敏、熱響應時間快、質量穩定、使用壽命長等特點。
特點
★ 熱響應時間短，減小動態誤差
★ 直徑小，長度不受限制
★ 測量精確度高
★ 進口薄膜電阻元件，性能可靠穩定
工作原理
鎧裝鉑電阻是利用物質在溫度變化時，其電阻值也隨著發生變化的特征來測量溫度的，當阻值變
化時，工作儀表便顯示出阻值所對應的溫度值。
|
