角型電感式接近開關PL-08D2 價格
產品概述
角型電感式接近開關PL-08D2是一款專為工業自動化設計的非接觸式感應裝置，采用方形外殼結構（17mm×17mm×35mm），適合空間受限的安裝場景。其核心原理基于電磁感應，通過高頻振蕩器檢測金屬目標物的接近，輸出穩定的開關信號。產品支持直流三線制接線，提供常開（NO）或常閉（NC）輸出模式，兼容10-36VDC寬電壓輸入，適應多種控制系統需求。檢測距離為8mm，響應頻率達400Hz，可精準捕捉快速移動的金屬物體，適用于機械定位、流水線計數等場景。外殼采用金屬材質，具備優異的抗干擾性和機械強度，防護等級滿足工業環境要求。
English Overview
The PL-08D2 angular inductive proximity switch is a non-contact sensing device designed for industrial automation, featuring a compact square housing (17mm×17mm×35mm) ideal for space-constrained installations. Utilizing electromagnetic induction technology, it detects metal targets via high-frequency oscillation and delivers stable switching signals. Compatible with DC 3-wire systems, it offers both normally open (NO) and normally closed (NC) output modes, supporting a broad voltage range of 10-36VDC for diverse control systems. With an 8mm sensing range and 400Hz response frequency, it ensures precise detection of fast-moving metal objects, suitable for applications like mechanical positioning and conveyor counting. The metal housing enhances durability and electromagnetic interference resistance, meeting industrial environmental standards.
功能與性能
PL-08D2在復雜工況下表現穩定，內置抗干擾電路，可抵御油污、粉塵等環境干擾。其角型設計便于多角度安裝，配合鎖緊螺母實現牢固固定。產品工作溫度范圍寬（-25℃~70℃），適應高溫或低溫車間環境。此外，LED狀態指示燈直觀顯示開關動作，便于現場調試。
Features & Performance
The PL-08D2 excels in harsh conditions with built-in anti-interference circuits, resisting oil, dust, and electromagnetic noise. Its angular design allows flexible multi-angle mounting, secured by locking nuts for stability. Operating within -25℃ to 70℃, it performs reliably in extreme temperatures. An integrated LED status indicator simplifies on-site troubleshooting and operational monitoring.
應用領域
廣泛應用于機床、包裝設備、電梯安全檢測等場景，例如檢測金屬工件到位、傳送帶物料計數或機械臂極限位置控制。在汽車制造中，可用于焊接機器人或裝配線的精密定位。
Applications
Widely used in machine tools, packaging systems, and elevator safety checks, such as detecting metal part presence, conveyor counting, or robotic arm positioning. In automotive manufacturing, it ensures precision in welding robots and assembly line operations.
服務與可靠性
提供一年質保服務，產品經嚴格出廠測試，確保長期穩定運行。用戶可根據需求選擇不同線纜長度或插頭配置的定制方案。
Service & Reliability
Backed by a one-year warranty, each unit undergoes rigorous factory testing for enduring performance. Custom options like cable lengths or connector types are available upon request.
引用來源：
481327
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
