角型電感式接近開關SN04-N2 供應
中文介紹
角型電感式接近開關SN04-N2是一種高性能的傳感器設備，廣泛應用于工業自動化領域。它采用先進的電感式感應技術，能夠非接觸式地檢測金屬物體的存在。該接近開關具有直流三線NPN常閉輸出形式，額定電壓范圍為DC 10-30V，能夠適應多種電壓環境。其檢測距離為4mm，能夠精確地感應到金屬物體，同時響應頻率高，可滿足快速檢測的需求。此外，該產品還具備良好的防水防塵性能，防護等級達到IP66，能夠在較為惡劣的工業環境中穩定工作。其外殼材質為ABS，堅固耐用，安裝方式為螺絲固定，方便用戶根據實際需求進行安裝。
English Introduction
The SN04-N2 corner type inductive proximity switch is a high-performance sensor device widely used in the field of industrial automation. It employs advanced inductive sensing technology to non - contactly detect the presence of metal objects. This proximity switch features a direct current three - wire NPN normally closed output form and a rated voltage range of DC 10 - 30V, making it adaptable to various voltage environments. With a detection distance of 4mm, it can accurately sense metal objects and offers a high response frequency to meet the needs of rapid detection. Moreover, the product is equipped with excellent waterproof and dustproof performance, with a protection rating of IP66, ensuring stable operation in harsh industrial environments. Its housing is made of ABS material, which is durable and robust, and the installation method is screw - fixed, facilitating user - friendly installation according to actual requirements.
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
