WZP-621AB 工業測溫熱電阻（中英文產品說明）
產品概述
WZP-621AB型熱電阻是專為電站系統開發的溫度檢測元件，適用于汽輪機、鍋爐機組及管道系統的溫度監測場景。產品采用模塊化設計理念，通過優化傳感器結構與接線方式，滿足電力行業對測量設備長周期穩定運行的特殊要求。該系列產品可在-50℃～+650℃溫度范圍內實現實時數據采集，為設備安全運行提供可靠保障。
核心優勢
-
環境適應性
采用316L不銹鋼防護套管與氧化鋁絕緣體組合結構，有效抵御水汽凝結、介質沖刷及振動干擾。特殊設計的錐形螺紋接口可適配多種安裝工況，確保在高壓環境下的密封性需求。
-
測量穩定性
通過精密焊接工藝將鉑電阻元件與引線結合部進行多重保護，配合真空燒結工藝制造的陶瓷絕緣體，實現溫度漂移量≤0.1%/年。多層防震結構設計使產品在20Hz～500Hz振動環境下仍保持穩定輸出。
-
維護便利性
標準化插接式端子設計支持不斷電快速更換，分體式接線盒蓋結構簡化現場維護流程。產品提供G1/2、M27×2等五種標準接口規格，兼容主流電站設備安裝需求。
典型應用
• 汽輪機軸承溫度監測
• 高壓蒸汽管道溫度監控
• 發電機冷卻系統溫度檢測
• 鍋爐受熱面管壁測溫
• 輔機設備運行溫度采集
選型指導
用戶可根據具體工況選擇直型、角型或可旋轉探頭結構，防護套管長度支持80mm～1000mm定制。常規配置包含4芯屏蔽電纜（可選PTFE或硅橡膠護套），特殊環境可選用鎧裝加強型結構。
服務支持
我們提供專業技術團隊協助選型設計，配套安裝指導手冊與調試建議。產品交付周期為合同確認后15個工作日，支持非標參數定制開發。
WZP-621AB Industrial Temperature Sensor (Bilingual Product Introduction)
Product Profile
The WZP-621AB thermal resistor is engineered for temperature monitoring in power station systems, particularly suited for turbine units, boiler systems, and pipeline networks. Featuring modular construction and optimized sensor configuration, this device delivers continuous temperature data within -50℃ to +650℃ range, supporting critical equipment protection in demanding environments.
Technical Highlights
-
Environmental Resistance
Combined 316L stainless steel sheath and alumina insulator structure provides protection against moisture ingress, medium erosion, and mechanical vibration. Tapered thread connections ensure reliable sealing under high-pressure conditions.
-
Measurement Consistency
Multi-layer protection for platinum sensing elements through precision welding techniques, coupled with vacuum-sintered ceramic insulation, achieves annual drift rate below 0.1%. Vibration-damping architecture maintains signal stability under 20Hz-500Hz oscillation.
-
Maintenance Efficiency
Quick-disconnect terminals enable tool-free replacement without system shutdown. Detachable junction box design simplifies field service procedures. Five standardized interfaces (including G1/2 and M27×2) ensure compatibility with major power equipment.
Application Scenarios
• Turbine bearing temperature monitoring
• High-pressure steam piping supervision
• Generator cooling system analysis
• Boiler heat surface measurement
• Auxiliary equipment thermal management
Configuration Options
Select from straight, angled, or rotatable probe configurations with protective sheath lengths from 80mm to 1000mm. Standard models include 4-core shielded cables (PTFE/silicone options available), with armored variants for extreme conditions.
Service Commitment
Our engineering team provides customized selection guidance and installation support. Standard delivery within 15 business days after order confirmation, accepting parameter customization for special application requirements.
