角型電感式接近開關SN04-P 廠家
產品概述
角型電感式接近開關SN04-P是一款高性能的非接觸式檢測設備，采用電磁感應原理設計，適用于工業自動化控制系統中金屬物體的位置檢測。該產品外形采用堅固耐用的角柱型結構，安裝靈活便捷，可廣泛應用于機械制造、物流輸送、包裝設備等多種工業場景。產品具有反應速度快、使用壽命長、抗干擾能力強等特點，能夠在復雜工業環境中穩定工作。1823
技術特點
SN04-P采用直流三線制PNP輸出方式，工作電壓范圍為DC6-36V，檢測距離可達4mm±10%。產品內置高品質感應線圈和信號處理電路，能夠精確檢測鐵、鋼等金屬物體的接近狀態，輸出穩定的開關信號。其外殼采用工程塑料或金屬材質，具備良好的防水、防塵和抗沖擊性能，可在-20℃至+60℃的溫度范圍內正常工作。產品設計緊湊，尺寸為18×18×36mm，適合空間受限的安裝環境。61620
應用場景
This inductive proximity switch is widely used in automated production lines for position detection of mechanical arms, conveyor belts and tooling fixtures. It can also be applied in logistics identification systems and equipment protection devices to achieve real-time monitoring of object position and status. The product s high reliability makes it suitable for harsh industrial environments including those with oil, dust or vibration. Its non-contact detection method eliminates mechanical wear and ensures long service life.919
產品優勢
The SN04-P series offers excellent performance with fast response time up to 200Hz and stable operation under voltage fluctuations. Its optimized circuit design provides complete short-circuit and reverse polarity protection. The product features all-stainless steel housing options for food processing applications and high-pressure cleaning environments. With standardized mounting dimensions and multiple output configurations, it can easily replace similar products in existing systems while providing enhanced detection performance.1424
服務支持
We provide comprehensive technical support and customization services for the SN04-P proximity switch. Customers can choose from various cable lengths, connector types and special housing materials according to application requirements. Our global distribution network ensures fast delivery and local service support. The product s modular design facilitates maintenance and replacement, minimizing downtime in production systems.2128
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
